auto-auto-grid-detection met unchanged auto

Process the fixture with Auto and the default settings only, with no case-specific options, and keep the automatic classification, route, and output grid identical to the approved baseline. The target comparison additionally measures how far the output still is from the fixed target image.

Changed pixels: 0 (0.00%)

Time: 20688.37ms

All images and settings

Input (2375x1344px)
Input
Ground truth (88x61px)
Ground truth
Baseline (88x61px)
Baseline
Result (88x61px)
Result
Ground-truth difference (88x61px)
Ground-truth difference
Baseline difference (88x61px)
Baseline difference
Background mask (88x61px)
Background mask

Metric comparison

Metric Target Baseline Current Delta Verdict
Output size correct 88x61px 88x61px - passed
meanRgbaError - 0 0 0 metric unchanged
edgeF1 - 1 1 0 metric unchanged
backgroundMaskIou - 1 1 0 metric unchanged
smallComponentRetention - 1 1 0 metric unchanged

Regressed metrics: none

Target comparison

met

Target source: trim-auto-grid

Output size88x61px
Size matchesyes
Exact matchyes
Mean RGBA error0
Edge F11
Background mask IoU1
Small component retention1

WARNING details

WARNING presentation: none

none

Auto candidate diagnostic

Candidate list
would-not-show
Decision reason
NO_WARNING NO_WARNING
Classification confidence
0.7788
Grid confidence
0.4961
Candidate plans
6

Candidate options

No candidate option was generated

Options

Input kind
unclassified
Route
refine
Grid confidence
0.4961
Top candidates
[{"width":203,"height":116,"score":0.6966890201862613,"confidence":0.49609566489440726},{"width":163,"height":91,"score":0.6570429214667656,"confidence":0.4601451476162112},{"width":133,"height":75,"score":0.6559674085193886,"confidence":0.45969616618592474}]
Metrics
{"outputWidth":88,"outputHeight":61,"sizeCorrect":true,"top3SizeCorrect":true,"gridPhaseError":12.889716840536558,"meanRgbaError":0,"edgeF1":1,"backgroundMaskIou":1,"smallComponentRetention":1,"byteIdentical":true,"catastrophicFailure":false,"runtimeMs":20688.366994999997,"approxPeakBytes":12810944}
Options
{"detectionQuantStep":64,"backgroundMaskTolerance":0,"autoMaxCellsW":512,"autoMaxCellsH":512,"backgroundTolerance":64,"sampleWindow":3,"maxSamplesPerCell":32,"cellAlphaThreshold":16,"trimAlphaThreshold":16,"processingMode":"auto","detailLevel":"balanced","cellScale":"same","preRemoveBackground":true,"postRemoveBackground":true,"bgExtractionMethod":"auto","bgRemovalScope":"auto","bgConnectivity":"4","trimToContent":true,"preserveProcessingScale":true,"autoGridFromTrimmed":true,"fastAutoGridFromTrimmed":true,"enableGridDetection":true,"makeSquare":false,"keepAspectRatio":false,"cellSamplingMode":"hard-alpha-medoid","preserveThinFeatures":true,"smallComponentMode":"auto","geminiWatermarkRemoval":"auto","backgroundMask":true,"gridSignals":{"colorBoundary":true,"luminanceAlphaGradient":true,"autocorrelation":true,"reconstruction":true,"localPhaseStability":true},"backgroundDehalo":true,"backgroundEdgeCleanup":true,"backgroundRampFollow":true,"backgroundRemovalRollback":true,"alphaBorderBackgroundGuard":true,"backgroundConfidenceGate":true,"smallComponentBackgroundGate":true,"phaseAwareGridSearch":true,"boundaryContrastOverride":true,"smallAspectGridAlignment":"on","watermarkSamplingCompat":"on","ditherMode":"none","ditherStrength":0,"outlineStyle":"none","outlineColor":{"r":255,"g":255,"b":255},"debug":false}
